8600 series
tractor series
These new generation Tractor 8600 Series tractors are a perfect blend of modern styling and high Performance
No.1
Tractor company in the world
by volume
Mahindra Tractor 8600 Series – Power and Precision for Professional Farming
The Mahindra Tractor 8600 Series is engineered to exceed the expectations of modern farmers who require serious performance. As a result, this series has become a trusted choice for high-output agricultural operations across South Africa.
Thanks to its high-horsepower engine and rugged structure, the Mahindra Tractor 8600 Series handles intensive farming tasks with ease. Whether you’re deep tilling, planting across expansive fields, or hauling loads over uneven terrain, this machine thrives. Moreover, its heavy-duty chassis ensures reliability even in the most demanding working conditions.
In fact, the Mahindra Tractor 8600 Series combines brute force with modern engineering. With a range of horsepower options and 2WD or 4WD configurations, it adapts effortlessly to varying terrains and operational needs. That’s why farmers across the Lowveld rely on this series for their toughest jobs.
Operator comfort is also front and center. The Mahindra Tractor 8600 Series includes a spacious, low-vibration cabin with suspension seating and easy-to-reach controls. Consequently, productivity stays high—even after long hours in the field.
Furthermore, the Mahindra Tractor 8600 Series is compatible with a wide range of implements, making it ideal for ploughing, planting, towing, and spraying. Its efficient hydraulic system ensures smooth and responsive control. Because of this, you can do more in less time—with less effort.
When it comes to maintenance, this series doesn’t disappoint. A low-maintenance engine, oil-immersed brakes, and simplified service points make the Mahindra Tractor 8600 Series a smart long-term investment. So, downtime is minimized, and your farm keeps running strong.
At Mahindra Nelspruit, we carry the entire Mahindra Tractor 8600 Series range. Whether you’re investing in your first unit or expanding your fleet, our team is ready to assist. Additionally, we offer demo drives, finance options, and full after-sales support.
Ultimately, the Mahindra Tractor 8600 Series delivers unmatched versatility, comfort, and raw power. Visit Mahindra Nelspruit today and experience the performance that only the Mahindra Tractor 8600 Series can offer.
Ideal for
LIVESTOCK
DAIRY
HAY & FORAGE
LIVESTOCK
HAULAGE
Features
Dedicated to Southern African Farms
These tractors are specially made for dryland farming & livestock, dairy applications.
5,000 KG
LIFT CAPCITY
4400 cc
DISPLACEMENT
110 Hp
Peak Power
Highly fuel efficient
Saves up to 3000 Litres in 1 Year
Additionally, they come with the tried-and-tested, well-known Perkins 4-cylinder turbocharged intercooler engine and ZF transmission, which together offer a formidable combination of power and versatility.
Engine
18.2 % Back-Up Torque.
416 Nm Torque @ 1400 Rpm.
16F / 16 R ZF Transmission.
Best in class
Independent Four Speed,
Electrohydraulic Actuation,
Mechanical Control, (430 / 540 / 540e / 1000)
MODELS IN THE 8600 SERIES
86-110 P
ENGINE OUTPUT
83.0 KW
PTO HP
--
CYLINDER
4
WEIGHT
4950 kg
LIFT CAPACITY
5000 kg
TRANSMISSION
Power shift Hi-Lo
SPECIFICATIONS
ENGINE
| Engine | 86-110 P |
|---|---|
| EMISSIONS | Stage III-B (Interim Tier 4) |
| MODEL | PERKINS 1104D-44TA Turbocharged & Intercooled |
| POWER | 110 HP @ 2200 RPM |
| PTO POWER | 85% of Engine Power |
| MAX SPEED | 2400 RPM |
| TORQUE | 416Nm @ 1400 RPM |
| ASPIRATION | Turbocharged, Intercooled |
| AIR FILTER | Dry Tape With Pre-Internal Filter |
| BORE X STROKE | 99 mm x 110 mm |
| CYLINDERS | 4 |
| CYLINDERS-CUBIC CAPACITY (CC) | 4400 cc |
CLUTCH
| TRANSMISSION | |
|---|---|
| TYPE | Power Shift Hi-Lo |
| NUMBER OF GEARS / SPEEDS | 16 Forward & 16 Reverse |
PTO
| TRANSMISSION | |
|---|---|
| TYPE | Independent Electro Hydrailic |
| SERVO-PTO Coverage | 430-540-540E-1000 |
HYDRAULIC SYSTEM
| Hydraulics | |
|---|---|
| TYPE | Electronical |
| THREE POINT LINKAGE | Cat II |
| CONTROL | Electro-Hydraulic |
| LIFT CAPACITY | 5000 Kg |
| REAR AUXILARY REMOTE VALVES | 4 Spool |
OTHER
| OTHER | |
|---|---|
| DRIVE SYSTEM | 4WD |
| STEERING | Hydrostatic Power Steering |
| BRAKE TYPE | Oil Immersed Brake |
ELECTRICAL
| Electrical | |
|---|---|
| BATTERY CAPACITY | 12V, 115Ah |
| ALTERNATOR | 120 A |
DIMENSION WITH AG TYRES
| Dimensions | |
|---|---|
| LENGTH | 4455 mm |
| WHEELBASE | 2405 mm |
| WIDTH | 2030 mm |
Gallery
Unique selling point
TOUGH
Best-in-class engine torque
The Perkins 4 cylinder 1104D- 44T turbocharged intercooler engine in these tractors offer an unmatched combination of best-in-class engine power, fuel efficiency and reliability. They are designed to offer maximized torque levels as high as 416 Nm at a low Rpm of 1400 that ensures high productivity in both PTO and draft applications.
Best-in-class lift capacity
The tractor comes with 4 sets of remote standard auxiliary valves giving it the ability to work with different heavy hydraulic implements. The hydraulics operate at a high pressure of 190Mpa & allow heavy loads up to 5000 kg to be lifted. The Automatic Lifting System (ALS) may be controlled mechanically or electrically. ALS is generally used to lift the equipment at the end of the groove while ploughing without changing the settings of hydraulic control levers, and to lower the equipment to the previous setting providing the same ploughing depth at every position in the field. The ALS is used to operate equipment such as a trailer, loader, excavator, rotary plough, etc.
EFFICIENT
Lowest-rated engine speed
The Low rated engine speed ensures lower fuel consumption and less wear and tear of engine components.
Best-in-class PTO
The independent PTO lever offer ease in engagement & disengagement during all PTO-driven applications ensuring economy speeds for efficient operation with a variety of implements.
Traction system
The four-wheel-drive lever locking mechanism is activated with a lever in this model. It is performed electronically. Four-wheel drive may be activated or deactivated at all gear ranges, at fixed and low speeds that the tractor moves. Four-wheel drive shall be activated so that you can obtain maximum efficiency from your tractor in rough terrain conditions. Slipping is reduced and the service life of tires is increased when the four-wheel drive is activated for tires that slip with a two-wheel drive.
EFFORTLESS
Lowest-rated engine speed
It comes with numerous features & options to assure you a comfortable working experience. Built-in air compressor system for tyre inflation, air trailer brake, 2-way adjustable operator seats ensures superior comfort & steering. The easy access to all controls & levers & illumination at 8 different locations ensure the comfort & convenience of the operator. With sufficient ground clearance of 520 mm, it is suitable to work on uneven surfaces. Radio / CD Player, an air-conditioned cabin / Heater and ventilation system are standard. Another standout feature is the Height & tilt adjustable cabin. Lastly, the electronic push-button activated PTO offer ease in engagement & disengagement during all PTO-driven applications.
Best in class transmission speeds
The ZF T-557 L transmission provides smooth shifting on the move. The standard 16F+16R speeds maximize performance in different applications & terrain. It allows the tractor to work in a wide range of speeds from 2.20 to 39.30 km/hour. It comes with a Power Shift & button activated Differential Lock. It also has a dry mechanically controlled clutch with large 12” Cerametallic plates for longer life. The forward/reverse shuttle shuttle (4WD) makes shifting between forward and reverse smooth and quick, thereby ensuring maximum productivity during intense loader and headland operations. The Synchromesh heavy-duty transmission is extremely reliable and easy to use. It eliminates the need to depress the clutch every time the tractor needs to change direction, forward or reverse and the high number of speeds options allows performing a broad range of farming applications most efficiently.
